Working Principle of Containerized STP:
- Pre-treatment: Large solids and debris are removed by screens and settling tank.
- Biological Treatment (Secondary): Biological treatment converts dissolved organic contaminants into simpler products by the use of microorganisms (such as those in activated sludge).
- Settling/Clarification: In a clarifier, the microbial sludge is separated by settling and is drawn away leaving the water.
- Tertiary / Disinfection: Additional treatment and disinfection of the water eliminate pathogens and further purifies the water prior to discharge or reuse.
Containerized STP Treatment Technologies:
Being as premier containerized STP manufacturers in Maharashtra, India, according to organic material there is treatment technology that we provided which as given below.
- Activated Sludge Process (ASP): This is a type of biological treatment which involves the use of microorganisms suspended in wastewater in order to decompose organic substances.
- Sequential Batch reactor (SBR): Containerized STP suppliers in Maharashtra, India is a form of ASP in which wastewater is treated in batches and is operated using a discrete fill, react, settle, decant, and idle phase.
- Membrane Bio-Reactor (MBR): This is a highly developed technology that integrates both biological treatment and ultrafiltration or microfiltration membrane to filter out the contaminants to produce a high-quality effluent and also occupies less space unlike the traditional ASP systems.
Technical Specification of Containerized STP:
We've added below a specialized table of containerized STP in Maharashtra, India that provides further technical specification information.
| Parameter |
Specification |
| Type |
Packaged / Containerized STP |
| Capacity |
10 – 500 KLD |
| Container Size |
20 ft / 40 ft ISO |
| Process |
MBBR / MBR / SBR |
| Stages |
Screening → Equalization → Biological → Clarification → Filtration → Disinfection |
| Effluent Norms |
BOD ≤ 10 mg/L, COD ≤ 50 mg/L, TSS ≤ 10 mg/L |
| Construction |
MS epoxy coated / FRP lined / SS |
| Pumps & Blowers |
Submersible pumps (SS), Twin-lobe blowers |
| Aeration |
Fine bubble diffusers |
| Automation |
PLC/SCADA or semi-auto |
| Power |
5 – 50 kW (as per capacity) |
Key Characteristics of Containerized STPs:
As containerized STP suppliers in Maharashtra, India, according to abilities there is different key characteristics which are given below.
- Modularity: The whole treatment system is already installed and verified in a single or a series of ISO standard containers.
- Transportation and installation Ease: Containerized STP manufacturers in Maharashtra, India, modular design is easy to transport both by land and sea and has a plug and play design that enables a quick on-site installation.
- Space-Saving: The integrated design is usually compact in space when compared to the traditional STPs.
- Customization: Systems may be customized to suit unique customer demands and abilities in containerized STP exporters in Maharashtra, India.
- Uses: Containerized wastewater treatment system good in remote locations, mining camps and temporary installations where a fixed plant cannot be economically justified.
Benefits of Containerized STP:
As premier containerized STP exporters in Maharashtra, India, we provided different benefits according to industrial requirement which as follow.
- Plug and Play System: Fully piped and wired and is ready to start working immediately once it is hooked to power and sewage systems. This guarantees a rapid commissioning that keeps you saving important project time and labour expenses.
- Small & Portable Construction: Containerized STP manufacturers in Maharashtra, India can be placed in a small space and is designed into a standard ISO container, which is small, and can be located anywhere in a crowded city or even an isolated area.
- High Quality of Output: Superior produces high quality treated water levels through the use of advanced technology such as MBBR or MBR. The resultant water can be reused safely in gardens, flushing or cooling industries.
- Weatherproof and durable: The hardy container frame ensures that all the internal equipment is not exposed to bad weather, corrosion, and theft. This ensures increased life cycle and reduced maintenance problems even in the adverse environments.
Applications of Containerized STP:
Serve as premier containerized STP manufacturers in Maharashtra, India, it is applicable in different centers which are given below.
- Construction Sites and Labor Camps: Offers an immediate and temporary sewage treatment to worker colonies and project sites that are of short duration. It guarantees the local environmental conformity during the construction stage.
- Hotels & Resorts: Ideal to hospitality business in remote or ecologically sensitive locations where the landscape is not to be disturbed too much. It can manage variable sewage loads effectively and at the same time has a high standard of the environment.
- Military Camps & Disaster Relief Zones: Provides the ability to be deployed anywhere quickly in case of remote bases or emergencies where the establishment of critical infrastructure is the most crucial.
- Small Residential Townships: Best suited in new housing development or small colonies where a decentralized sewage treatment is required prior to connecting to the main municipal line. It is a low-price and expandable community sanitation solution.
- Educational Campuses & Hospitals: Good on institutions that have limited land space and have stringent requirements to the reuse of water.
What is the reason we should use Containerized STP?
- CRISIL-rated Manufacturing: We have a high quality rating that supports our business and gives our products reliability and our business a transparent operation.
- Experienced Design and Engineering: Technocrats who have been incorporated, and they are very experienced in the field of R&D, Design, and Engineering of water solutions.
The Ideal System & Services is leading containerized STP manufacturers, suppliers, exporters in Maharashtra, India, which is both sustainable and realistic to the contemporary infrastructure. They are able to address the significant project development limitations such as land scarcity and time; we have a durable, compliant, and easy-to-install system designed with a long lifespan.
It is able to be environmentally responsible by ensuring effective treatment of sewage, encouraging reuse and recycling of water. C-STP is not only a product, STP inbox plant manufacturer is a smart investment in a greener cleaner future in India and other places. Contact us for more details.
